LOCAL BOARD CV59SH-032U MAIN BOARD, Mother Board #wb22

The image shows a portion of an EVB-LAN9668 Evaluation Board, a development tool for the Microchip LAN9668 TSN Ethernet Switch.

Purpose:

The EVB-LAN9668 is designed for evaluating and developing solutions using the LAN9668 TSN (Time Sensitive Networking) Ethernet Switch.

Features:

It includes 8 Gigabit Ethernet ports, an external DPLL for precise PTP time synchronization, and PCIe and expansion headers for prototyping and integration.

Components:

The board incorporates the LAN9668 switch and LAN8814 PHYs (Physical Layer devices) for Ethernet connectivity.

Applications:

This evaluation board is useful for rapid prototyping, software development, and system integration in applications requiring advanced Ethernet switching capabilities, particularly those utilizing Time Sensitive Networking.
